1. 快速入门
1.1. 简介
如上图，本实例主要实现一个网站登录的过程，登录对年龄有要求，如果满18岁，允许其登录，否则劝其离开：
- 输入姓名和名称
- 如果年龄大于等于18岁，则欢迎用户登录此站（什么站就不说了），祝其玩得愉快；
- 如果年龄小于18岁，告诉其年龄太小，劝其离开。
1.2. 环境准备
- Maven
- Java运行环境
1.3. 快速入门
1.3.1. 创建maven项目
最终项目结构如下：
quick-start
--src
----main
------java
--------samples.activiti
----------WebsiteLogonProcessEngine.java
----------YoungManProcess.java
------resources
--------logon-bpmn20.xml
--------logback.xml
--pom.xml
1.3.2. pom.xml
<project xmlns="http://maven.apache.org/POM/4.0.0"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>
<groupId>samples.activiti</groupId>
<artifactId>quick-start</artifactId>
<version>1.0-SNAPSHOT</version>
<packaging>jar</packaging>
<name>quick-start</name>
<properties>
<project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
<activiti.version>5.22.0</activiti.version>
<h2db.version>1.4.193</h2db.version>
<slf4j.version>1.7.21</slf4j.version>
<logback.version>1.1.7</logback.version>
</properties>
<dependencies>
<!-- activiti engine -->
<dependency>
<groupId>org.activiti</groupId>
<artifactId>activiti-engine</artifactId>
<version>${activiti.version}</version>
</dependency>
<!-- h2database -->
<dependency>
<groupId>com.h2database</groupId>
<artifactId>h2</artifactId>
<version>${h2db.version}</version>
</dependency>
<!-- <dependency>
<groupId>mysql</groupId>
<artifactId>mysql-connector-java</artifactId>
<version>5.1.41</version>
</dependency> -->
<!-- slf4j -->
<dependency>
<groupId>org.slf4j</groupId>
<artifactId>slf4j-api</artifactId>
<version>${slf4j.version}</version>
</dependency>
<!-- <dependency>
<groupId>org.slf4j</groupId>
<artifactId>slf4j-log4j12</artifactId>
<version>${slf4j.version}</version>
</dependency> -->
<!-- logback -->
<dependency>
<groupId>ch.qos.logback</groupId>
<artifactId>logback-classic</artifactId>
<version>${logback.version}</version>
</dependency>
</dependencies>
</project>
1.3.3. 创建流程引擎
创建WebsiteLogonProcessEngine.java文件，数据库使用h2database:
package samples.activiti;
import org.activiti.engine.FormService;
import org.activiti.engine.HistoryService;
import org.activiti.engine.ProcessEngine;
import org.activiti.engine.ProcessEngineConfiguration;
import org.activiti.engine.RepositoryService;
import org.activiti.engine.RuntimeService;
import org.activiti.engine.TaskService;
import org.activiti.engine.form.FormData;
import org.activiti.engine.form.FormProperty;
import org.activiti.engine.history.HistoricActivityInstance;
import org.activiti.engine.impl.cfg.StandaloneProcessEngineConfiguration;
import org.activiti.engine.impl.form.DateFormType;
import org.activiti.engine.impl.form.LongFormType;
import org.activiti.engine.impl.form.StringFormType;
import org.activiti.engine.repository.Deployment;
import org.activiti.engine.repository.ProcessDefinition;
import org.activiti.engine.runtime.ProcessInstance;
import org.activiti.engine.task.Task;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import java.text.DateFormat;
import java.text.ParseException;
import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.HashMap;
import java.util.List;
import java.util.Map;
import java.util.Scanner;
/**
* 流程引擎入门DEMO, 此DEMO实现流程如下:
* 1. 输入姓名和名称
* 2. 如果年龄大于等于18岁，则欢迎用户登录此站（什么站就不说了），祝其玩得愉快；
* 3. 如果年龄小于18岁，告诉其年龄太小，劝其离开。
*
* @author zilaiye
* @date 2017/10/27
*/
public class WebsiteLogonProcessEngine {
public static final Logger logger = LoggerFactory.getLogger(WebsiteLogonProcessEngine.class);
public static void main(String[] args) throws ParseException {
// 1. 配置 Activiti 流程引擎
ProcessEngineConfiguration cfg = new StandaloneProcessEngineConfiguration()
.setJdbcUrl("jdbc:h2:mem:activiti;DB_CLOSE_DELAY=1000")
.setJdbcUsername("sa")
.setJdbcPassword("")
.setJdbcDriver("org.h2.Driver")
.setDatabaseSchemaUpdate(ProcessEngineConfiguration.DB_SCHEMA_UPDATE_TRUE);
// 2. 获取 Activiti 流程引擎对象
ProcessEngine processEngine = cfg.buildProcessEngine();
String pName = processEngine.getName();
String ver = ProcessEngine.VERSION;
System.out.println("获取流程引擎对象完成: ProcessEngine Name: [ " + pName + " ] Version: [ " + ver + " ]");
// 3. 加载流程定义
RepositoryService repositoryService = processEngine.getRepositoryService();
Deployment deployment = repositoryService.createDeployment().addClasspathResource("logon-bpmn20.xml").deploy();
ProcessDefinition processDefinition = repositoryService.createProcessDefinitionQuery().deploymentId(deployment.getId()).singleResult();
System.out.println("发现流程定义, 名称:[" + processDefinition.getName() + "] Id:[" + processDefinition.getId() + "]");
////
// 4. 运营流程实例
RuntimeService runtimeService = processEngine.getRuntimeService();
// 启动一个流程实例
ProcessInstance processInstance = runtimeService.startProcessInstanceByKey("yellow-site-logon");
System.out.println("登录判断流程开始,流程实例ID:[" + processInstance.getProcessDefinitionId() + "] key:[" + processInstance.getProcessDefinitionKey() + "]");
// 流程中的任务
TaskService taskService = processEngine.getTaskService();
FormService formService = processEngine.getFormService();
HistoryService historyService = processEngine.getHistoryService();
Scanner scanner = new Scanner(System.in);
while (processInstance != null && !processInstance.isEnded()) {
// 获取流程的所有运行任务
List<Task> tasks = taskService.createTaskQuery().taskCandidateGroup("managers").list();
System.out.println("此流程共有任务数量: [ " + tasks.size() + "]");
// 循环任务执行之
for (int i = 0; i < tasks.size(); i++) {
Task task = tasks.get(i);
System.out.println("开始执行流程任务: [" + task.getName() + "]");
Map<String, Object> variables = new HashMap<String, Object>();
FormData formData = formService.getTaskFormData(task.getId());
for (FormProperty formProperty : formData.getFormProperties()) {
if (StringFormType.class.isInstance(formProperty.getType())) {
System.out.println(formProperty.getName() + "?");
String value = scanner.nextLine();
variables.put(formProperty.getId(), value);
} else if (LongFormType.class.isInstance(formProperty.getType())) {
System.out.println(formProperty.getName() + "? (Must be a whole number)");
Long value = Long.valueOf(scanner.nextLine());
variables.put(formProperty.getId(), value);
} else if (DateFormType.class.isInstance(formProperty.getType())) {
System.out.println(formProperty.getName() + "? (Must be a date m/d/yy)");
DateFormat dateFormat = new SimpleDateFormat("m/d/yy");
Date value = dateFormat.parse(scanner.nextLine());
variables.put(formProperty.getId(), value);
} else {
System.out.println("<form type not supported>");
}
}
taskService.complete(task.getId(), variables);
System.out.println("流程处理完成, 现在开始回放处理过程:");
HistoricActivityInstance endActivity = null;
List<HistoricActivityInstance> activities = historyService.createHistoricActivityInstanceQuery()
.processInstanceId(processInstance.getId()).finished()
.orderByHistoricActivityInstanceEndTime().asc()
.list();
for (HistoricActivityInstance activity : activities) {
if (activity.getActivityType() == "startEvent") {
System.out.println("流程处理开始, 实例名称:[" + processDefinition.getName() + "] Key:[" + processInstance.getProcessDefinitionKey() + "] 开始处理时间: [" + activity.getStartTime() + "]");
}
if (activity.getActivityType() == "endEvent") {
// Handle edge case where end step happens so fast that the end step
// and previous step(s) are sorted the same. So, cache the end step
//and display it last to represent the logical sequence.
endActivity = activity;
} else {
System.out.println("-- " + activity.getActivityName()
+ " [" + activity.getActivityId() + "] "
+ activity.getDurationInMillis() + " ms");
}
}
if (endActivity != null) {
System.out.println("-- " + endActivity.getActivityName()
+ " [" + endActivity.getActivityId() + "] "
+ endActivity.getDurationInMillis() + " ms");
System.out.println("流程处理完成 " + processDefinition.getName() + " ["
+ processInstance.getProcessDefinitionKey() + "] "
+ endActivity.getEndTime());
}
}
// Re-query the process instance, making sure the latest state is available
processInstance = runtimeService.createProcessInstanceQuery().processInstanceId(processInstance.getId()).singleResult();
}
scanner.close();
}
}
运行查看日志,可以发现默认使用h2的sql脚本创建了一系列的表结构：
17:13:29.420 [main] DEBUG o.a.e.i.c.ProcessEngineConfigurationImpl - initializing datasource to db: jdbc:h2:mem:activiti;DB_CLOSE_DELAY=1000
17:13:29.430 [main] DEBUG org.apache.ibatis.logging.LogFactory - Logging initialized using 'class org.apache.ibatis.logging.slf4j.Slf4jImpl' adapter.
17:13:29.446 [main] DEBUG o.a.i.d.pooled.PooledDataSource - PooledDataSource forcefully closed/removed all connections.
17:13:29.628 [main] DEBUG o.a.i.d.pooled.PooledDataSource - Created connection 1351478315.
17:13:29.632 [main] DEBUG o.a.e.i.c.ProcessEngineConfigurationImpl - database product name: 'H2'
17:13:29.632 [main] DEBUG o.a.e.i.c.ProcessEngineConfigurationImpl - using database type: h2
17:13:29.633 [main] DEBUG o.a.i.d.pooled.PooledDataSource - Returned connection 1351478315 to pool.
17:13:30.506 [main] DEBUG o.a.e.i.interceptor.LogInterceptor -
17:13:30.506 [main] DEBUG o.a.e.i.interceptor.LogInterceptor - --- starting SchemaOperationsProcessEngineBuild --------------------------------------------------------
17:13:30.514 [main] DEBUG o.a.i.t.jdbc.JdbcTransaction - Opening JDBC Connection
17:13:30.515 [main] DEBUG o.a.i.d.pooled.PooledDataSource - Checked out connection 1351478315 from pool.
17:13:30.515 [main] DEBUG o.a.i.t.jdbc.JdbcTransaction - Setting autocommit to false on JDBC Connection [conn0: url=jdbc:h2:mem:activiti user=SA]
17:13:30.540 [main] INFO o.a.engine.impl.db.DbSqlSession - performing create on engine with resource org/activiti/db/create/activiti.h2.create.engine.sql
17:13:30.540 [main] DEBUG o.a.engine.impl.db.DbSqlSession - SQL: create table ACT_GE_PROPERTY (
NAME_ varchar(64),
VALUE_ varchar(300),
REV_ integer,
primary key (NAME_)
)
17:13:30.546 [main] DEBUG o.a.engine.impl.db.DbSqlSession - SQL: insert into ACT_GE_PROPERTY
values ('schema.version', '5.22.0.0', 1)
17:13:30.547 [main] DEBUG o.a.engine.impl.db.DbSqlSession - SQL: insert into ACT_GE_PROPERTY
values ('schema.history', 'create(5.22.0.0)', 1)
17:13:30.548 [main] DEBUG o.a.engine.impl.db.DbSqlSession - SQL: insert into ACT_GE_PROPERTY
values ('next.dbid', '1', 1)
# 中间省略创建表的过程
....
17:13:30.638 [main] INFO o.a.engine.impl.ProcessEngineImpl - ProcessEngine default created
17:13:30.643 [main] INFO samples.activiti.OnboardingRequest - ProcessEngine Name: [ default ] Version: [ 5.22.0.0 ]
Disconnected from the target VM, address: '127.0.0.1:53308', transport: 'socket'
Process finished with exit code 0
1.4. 未成年人处理
package samples.activiti;
import org.activiti.engine.delegate.DelegateExecution;
import org.activiti.engine.delegate.JavaDelegate;
import java.util.Date;
/**
* 未成年处理流程, 如果未成年, 劝其离开
*
* @author zilaiye
* @date 2017/10/27
*/
public class YoungManProcess implements JavaDelegate {
public void execute(DelegateExecution delegateExecution) throws Exception {
Date now = new Date();
delegateExecution.setVariable("autoWelcomeTime", now);
System.out.println("未成年处理流程: 对不起:["
+ delegateExecution.getVariable("fullName") + "], 你还未成年,再长大点再来吧。");
}
}
1.5. 流程文件：logon-bpmn20.xml
<?xml version="1.0" encoding="UTF-8"?>
<definitions xmlns="http://www.omg.org/spec/BPMN/20100524/MODEL" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:activiti="http://activiti.org/bpmn" xmlns:bpmndi="http://www.omg.org/spec/BPMN/20100524/DI" xmlns:omgdc="http://www.omg.org/spec/DD/20100524/DC" xmlns:omgdi="http://www.omg.org/spec/DD/20100524/DI" typeLanguage="http://www.w3.org/2001/XMLSchema" expressionLanguage="http://www.w3.org/1999/XPath" targetNamespace="http://www.activiti.org/processdef">
<process id="yellow-site-logon" name="YellowSiteLogon" isExecutable="true">
<!-- 开始事件 -->
<startEvent id="startLogon" name="Start" activiti:initiator="initiator"></startEvent>
<!-- 输入用户信息任务 -->
<userTask id="inputUserInfo" name="请输入用户信息:" activiti:assignee="${initiator}" activiti:candidateGroups="managers">
<extensionElements>
<activiti:formProperty id="fullName" name="请输入姓名" type="string"></activiti:formProperty>
<activiti:formProperty id="age" name="请输入年龄" type="long" required="true"></activiti:formProperty>
</extensionElements>
</userTask>
<!-- 连接开始事件和输入信息的流程线 -->
<sequenceFlow id="sid-1337EA98-7364-4198-B5D9-30F5341D6918" sourceRef="startLogon" targetRef="inputUserInfo"></sequenceFlow>
<!-- 唯一的判断网关, 默认未满18岁处理 -->
<exclusiveGateway id="decision" name="判断年龄是否满18岁" default="youngManPath"></exclusiveGateway>
<!-- 输入用户信息, 判断 -->
<sequenceFlow id="sid-42BE5661-C3D5-4DE6-96F5-73D34822727A" sourceRef="inputUserInfo" targetRef="decision"></sequenceFlow>
<!--<scriptTask id="automatedIntro" name="Generic and Automated Data Entry" scriptFormat="javascript" activiti:autoStoreVariables="false">-->
<!--<script><![CDATA[var dateAsString = new Date().toString();-->
<!--execution.setVariable("autoWelcomeTime", dateAsString);]]></script>-->
<!--</scriptTask>-->
<!-- 未成年分支 -->
<sequenceFlow id="youngManPath" sourceRef="decision" targetRef="youngManIntro"></sequenceFlow>
<serviceTask id="youngManIntro" name="对不起,你未成年,不能登录此网站" activiti:class="samples.activiti.YoungManProcess"></serviceTask>
<sequenceFlow id="sid-37A73ACA-2E23-400B-96F3-71F77738DAFA" sourceRef="youngManIntro" targetRef="endLogon"></sequenceFlow>
<!-- 如果已成年,欢迎之 -->
<sequenceFlow id="manPath" name=">18" sourceRef="decision" targetRef="manIntro">
<conditionExpression xsi:type="tFormalExpression"><![CDATA[${age >= 18}]]></conditionExpression>
</sequenceFlow>
<userTask id="manIntro" name="用户已成年,欢迎其进入成人世界" activiti:assignee="${initiator}" activiti:candidateGroups="managers">
<extensionElements>
<activiti:formProperty id="welcomeManTime" name="欢迎您,你已通过验证,输入你的生日,开启一段愉快旅程" type="date" datePattern="MM-dd-yyyy hh:mm"></activiti:formProperty>
</extensionElements>
</userTask>
<sequenceFlow id="sid-BA6F061B-47B6-428B-8CE6-739244B14BD6" sourceRef="manIntro" targetRef="endLogon"></sequenceFlow>
<!-- 结束事件 -->
<endEvent id="endLogon" name="End"></endEvent>
</process>
<bpmndi:BPMNDiagram id="BPMNDiagram_onboarding">
<bpmndi:BPMNPlane bpmnElement="yellow-site-logon" id="BPMNPlane_onboarding">
<bpmndi:BPMNShape bpmnElement="startLogon" id="BPMNShape_startOnboarding">
<omgdc:Bounds height="30.0" width="30.0" x="155.0" y="145.0"></omgdc:Bounds>
</bpmndi:BPMNShape>
<bpmndi:BPMNShape bpmnElement="inputUserInfo" id="BPMNShape_enterOnboardingData">
<omgdc:Bounds height="80.0" width="100.0" x="240.0" y="120.0"></omgdc:Bounds>
</bpmndi:BPMNShape>
<bpmndi:BPMNShape bpmnElement="decision" id="BPMNShape_decision">
<omgdc:Bounds height="40.0" width="40.0" x="385.0" y="140.0"></omgdc:Bounds>
</bpmndi:BPMNShape>
<bpmndi:BPMNShape bpmnElement="manIntro" id="BPMNShape_personalizedIntro">
<omgdc:Bounds height="80.0" width="100.0" x="519.0" y="15.0"></omgdc:Bounds>
</bpmndi:BPMNShape>
<bpmndi:BPMNShape bpmnElement="endLogon" id="BPMNShape_endOnboarding">
<omgdc:Bounds height="28.0" width="28.0" x="725.0" y="165.0"></omgdc:Bounds>
</bpmndi:BPMNShape>
<bpmndi:BPMNShape bpmnElement="youngManIntro" id="BPMNShape_automatedIntro">
<omgdc:Bounds height="80.0" width="100.0" x="520.0" y="255.0"></omgdc:Bounds>
</bpmndi:BPMNShape>
<bpmndi:BPMNEdge bpmnElement="sid-37A73ACA-2E23-400B-96F3-71F77738DAFA" id="BPMNEdge_sid-37A73ACA-2E23-400B-96F3-71F77738DAFA">
<omgdi:waypoint x="570.0" y="255.0"></omgdi:waypoint>
<omgdi:waypoint x="570.0" y="179.0"></omgdi:waypoint>
<omgdi:waypoint x="725.0" y="179.0"></omgdi:waypoint>
</bpmndi:BPMNEdge>
<bpmndi:BPMNEdge bpmnElement="sid-1337EA98-7364-4198-B5D9-30F5341D6918" id="BPMNEdge_sid-1337EA98-7364-4198-B5D9-30F5341D6918">
<omgdi:waypoint x="185.0" y="160.0"></omgdi:waypoint>
<omgdi:waypoint x="240.0" y="160.0"></omgdi:waypoint>
</bpmndi:BPMNEdge>
<bpmndi:BPMNEdge bpmnElement="automatedIntroPath" id="BPMNEdge_automatedIntroPath">
<omgdi:waypoint x="405.0" y="180.0"></omgdi:waypoint>
<omgdi:waypoint x="405.0" y="295.0"></omgdi:waypoint>
<omgdi:waypoint x="520.0" y="295.0"></omgdi:waypoint>
</bpmndi:BPMNEdge>
<bpmndi:BPMNEdge bpmnElement="personalizedIntroPath" id="BPMNEdge_personalizedIntroPath">
<omgdi:waypoint x="405.0" y="140.0"></omgdi:waypoint>
<omgdi:waypoint x="405.0" y="55.0"></omgdi:waypoint>
<omgdi:waypoint x="519.0" y="55.0"></omgdi:waypoint>
</bpmndi:BPMNEdge>
<bpmndi:BPMNEdge bpmnElement="sid-42BE5661-C3D5-4DE6-96F5-73D34822727A" id="BPMNEdge_sid-42BE5661-C3D5-4DE6-96F5-73D34822727A">
<omgdi:waypoint x="340.0" y="160.0"></omgdi:waypoint>
<omgdi:waypoint x="385.0" y="160.0"></omgdi:waypoint>
</bpmndi:BPMNEdge>
<bpmndi:BPMNEdge bpmnElement="sid-BA6F061B-47B6-428B-8CE6-739244B14BD6" id="BPMNEdge_sid-BA6F061B-47B6-428B-8CE6-739244B14BD6">
<omgdi:waypoint x="619.0" y="55.0"></omgdi:waypoint>
<omgdi:waypoint x="739.0" y="55.0"></omgdi:waypoint>
<omgdi:waypoint x="739.0" y="165.0"></omgdi:waypoint>
</bpmndi:BPMNEdge>
</bpmndi:BPMNPlane>
</bpmndi:BPMNDiagram>
</definitions>
1.6. 运行结果
1.6.1. 未成年处理
19:02:45.299 [main] INFO o.a.engine.impl.db.DbSqlSession - performing create on engine with resource org/activiti/db/create/activiti.h2.create.engine.sql
19:02:45.361 [main] INFO o.a.engine.impl.db.DbSqlSession - performing create on history with resource org/activiti/db/create/activiti.h2.create.history.sql
19:02:45.376 [main] INFO o.a.engine.impl.db.DbSqlSession - performing create on identity with resource org/activiti/db/create/activiti.h2.create.identity.sql
19:02:45.382 [main] INFO o.a.engine.impl.ProcessEngineImpl - ProcessEngine default created
获取流程引擎对象完成: ProcessEngine Name: [ default ] Version: [ 5.22.0.0 ]
19:02:45.409 [main] INFO o.a.e.i.bpmn.deployer.BpmnDeployer - Processing resource logon-bpmn20.xml
发现流程定义, 名称:[YellowSiteLogon] Id:[yellow-site-logon:1:4]
登录判断流程开始,流程实例ID:[yellow-site-logon:1:4] key:[yellow-site-logon]
此流程共有任务数量: [ 1]
开始执行流程任务: [请输入用户信息:]
请输入姓名?
zilaiye
请输入年龄? (Must be a whole number)
12
未成年处理流程: 对不起:[zilaiye], 你还未成年,再长大点再来吧。
流程处理完成, 现在开始回放处理过程:
流程处理开始, 实例名称:[YellowSiteLogon] Key:[yellow-site-logon] 开始处理时间: [Sun Oct 29 19:02:47 CST 2017]
-- Start [startLogon] 7 ms
-- 请输入用户信息: [inputUserInfo] 17307 ms
-- 判断年龄是否满18岁 [decision] 8 ms
-- 对不起,你未成年,不能登录此网站 [youngManIntro] 1 ms
-- End [endLogon] 0 ms
流程处理完成 YellowSiteLogon [yellow-site-logon] Sun Oct 29 19:03:04 CST 2017
1.6.2. 已成年处理
19:04:00.745 [main] INFO o.a.engine.impl.db.DbSqlSession - performing create on engine with resource org/activiti/db/create/activiti.h2.create.engine.sql
19:04:00.808 [main] INFO o.a.engine.impl.db.DbSqlSession - performing create on history with resource org/activiti/db/create/activiti.h2.create.history.sql
19:04:00.822 [main] INFO o.a.engine.impl.db.DbSqlSession - performing create on identity with resource org/activiti/db/create/activiti.h2.create.identity.sql
19:04:00.827 [main] INFO o.a.engine.impl.ProcessEngineImpl - ProcessEngine default created
获取流程引擎对象完成: ProcessEngine Name: [ default ] Version: [ 5.22.0.0 ]
19:04:00.853 [main] INFO o.a.e.i.bpmn.deployer.BpmnDeployer - Processing resource logon-bpmn20.xml
发现流程定义, 名称:[YellowSiteLogon] Id:[yellow-site-logon:1:4]
登录判断流程开始,流程实例ID:[yellow-site-logon:1:4] key:[yellow-site-logon]
此流程共有任务数量: [ 1]
开始执行流程任务: [请输入用户信息:]
请输入姓名?
zilaiye
请输入年龄? (Must be a whole number)
20
流程处理完成, 现在开始回放处理过程:
流程处理开始, 实例名称:[YellowSiteLogon] Key:[yellow-site-logon] 开始处理时间: [Sun Oct 29 19:04:02 CST 2017]
-- Start [startLogon] 6 ms
-- 请输入用户信息: [inputUserInfo] 5685 ms
-- 判断年龄是否满18岁 [decision] 8 ms
此流程共有任务数量: [ 1]
开始执行流程任务: [用户已成年,欢迎其进入成人世界]
欢迎您,你已通过验证,输入你的生日,开启一段愉快旅程? (Must be a date m/d/yy)
1/1/94
流程处理完成, 现在开始回放处理过程:
流程处理开始, 实例名称:[YellowSiteLogon] Key:[yellow-site-logon] 开始处理时间: [Sun Oct 29 19:04:02 CST 2017]
-- Start [startLogon] 6 ms
-- 请输入用户信息: [inputUserInfo] 5685 ms
-- 判断年龄是否满18岁 [decision] 8 ms
-- 用户已成年,欢迎其进入成人世界 [manIntro] 7513 ms
-- End [endLogon] 1 ms
流程处理完成 YellowSiteLogon [yellow-site-logon] Sun Oct 29 19:04:16 CST 2017
